AMT 07ES05C-1P 3/4" Str Cent End Suction Chem Pump

AMT 07ES05C-1P 3/4" - 2" Straight Centrifugal End Suction Chemical Pump
  • • Cast Iron Construction

  • • EPDM/EPR Mechanical Seal and O-Rings

  • • Discharge Port Rotates in 45? Increments

  • • Solids Handling, Clog Resistant Impeller

  • • 1/2 to 3 HP Dual Cycle 50/60 Hz TEFC 56J NEMA Single or Three Phase Motors

  • • 3/4" to 2" NPT Sizes

Call for Price

AMT Solids Handling End Suction Centrifugal pumps are designed for continuous-duty OEM, Industrial/Commercial and General Service applications including circulation, chemical processing, liquid transfer and cooling. Pull-from-rear design for easy service without disturbing any piping. Self-cleaning impellers to prevent clogging and handles solids up to 3/8" diameter depending on the model. Pumps are close coupled to Totally Enclosed Fan Cooled (TEFC) motors. Pumps are not self-priming and require flooded suction.
Additional Features
  • • Pull-From-Rear Design Permits Easy Servicing Without Disturbing Piping

  • • Multiple 1/2" NPT Drain Ports

  • • Self-cleaning Impeller

  • • Front Drain Plugs

  • • 303 Stainless Steel Motor Shaft

  • • 3-Phase models can also operate on 50 Hz (This will change full load amps and service factor, RPM and priming capabilities).

  • • NOTE: Electric supply for ALL motors must be within ?10% of nameplate voltage rating (e.g. 230V ?10%= 207 to 253).

  • • Hazardous Duty/Xplosion Proof motors available from stock ranging from 1 to 10 HP; Contact for info and lead time!


1Many AMT products are usually available to be shipped within 24 hours, however some may require a 7-10 day factory lead time - contact us for more information on product availability
2Image may not reflect actual product - Double check the AMT catalog for accurate product information.
